The best optical quality for the best value for money.
The Surgical Microscopes MC-M12 DFV stand out in the market by having features that serve various specialties with its excellence in optical quality, providing the user with greater amplitude to the observed field. In addition they come with an array of accessories that complement their use, ranging from Carona Binocular, USB Capture Kit, Image Capture, light splitter and others.
Microfocus controlled by pedal
The line MC-M12* of microscopes has powered microfocus system driven by pedal, seeking greater precision and convenience to the user, keeping your hands free during surgical procedures.
High Capacity Lighting System
The line MC-M12 of microscopes received innovations in light generator, providing 100,000 lux, automatic voltage and 2 halogen lamps for fast exchange in case of burns. Its ability to integrate video cameras to capture, makes it perfect for creating videos and documentation.
Head Ergo DFV
With Ergo Head DFV is possible tilting movement, increasing the comfort and mobility of the micro-surgeon and improving the visibility of the area being observed.
TECHNICAL SPECIFICATIONS
Microscopes |
Increase selection |
Drum type - 3 or 5 increases |
Objective |
250mm |
Eyepieces |
10x, 12.5x, 20x |
Binoculars |
Tilting - focus 155mm |
Increase total |
3 increases: 6x, 10x and 16x 5 increases: 4x, 6x, 10x, 16x and 25x |
Observed field |
3 increases: 34 mm, 21 mm, 13 mm 5 increases: 52mm, 34mm, 21mm, 13mm and 8mm |
Focus |
Manual/Auto |
|
Lighting |
System |
Lighting of coaxial cold light for fiber optic cable |
Light source |
15v halogen lamp 150w |
Lighting field |
50mm |
Lighting control |
Adjustment for generator button |
Filters |
Green to orange |
|
Stand |
Floor |
With rollers |
Maximum Arm Extension |
1177mm |
Vertical Arm Course |
580mm |
Base size |
740mm |
|
Other |
Weight |
73Kg |
Energy consumption |
260V |
Feeding source |
AC 100v - 240v |
|
